Gazelle Arroyo C5 Elite | Electric Bike

Choosing the Arroyo C5 Elite means opting for an elegant and comfortable package. Beautiful design lines combined with a low-maintenance belt and powerful mid-motor provide optimal convenience.

For those who like to take it easy, the Arroyo C5 Elite delivers comfort down to the last detail. For example, this model features Gazelle popular low and wide step-through and a cleverly designed charging port. The quiet and low-maintenance Gates belt and Shimano Nexus 5 e-bike hub, which allows you to shift gears under load, also make this e-bike very easy to use.

When designing the Arroyo C5 Elite, extra emphasis was placed on integration. The elegantly integrated battery makes it easy to read the charging status on the top. The leather handlebar grips and gel seat also provide a luxurious finish and extra comfort.

Whenever and wherever you cycle, you will enjoy that reassuring push from behind — especially when you're tackling a steep hill or cycling home loaded up with shopping. They've equipped the Arroyo C5 Elite with the Bosch Performance Line mid-drive motor (torque: 75 newton-meters). The assistance it provides is powerful, yet still feels completely natural. The engine and battery are also neatly integrated into the frame.

SPECIFICATIONS
E-BIKE
UI/REMOTE – Bosch Purion 200
BATTERY – Intube Bosch, 540Wh
CHARGER – 4 Ah
MOTOR – Bosch Smart System Performance Line (75Nm)

BIKE
FRAME – Stable, lightweight hydro-formed aluminium frame with 68.5° headset angle and 69.5° seat tube angle for relaxed and comfortable riding. This is a low-step and spacious frame, single tube and integrated cables
FORK – Aluminium, telescopic sprung
FRONT WHEEL – Shimano hub w/ Ryde ZAC421, Double-walled aluminium, 700c rim
REAR WHEEL – Shimano Nexus 5 hub w/ Ryde ZAC421, Double-walled aluminium, 700c rim
FRONT TIRE – Schwalbe Energizer Active Plus 700x47c
REAR TIRE – Schwalbe Energizer Active Plus 700x47c
CHAINRING – 46T
REAR DERAILLEUR – Shimano Nexus 5-speed Internal Gear Hub
COG – N/A
CHAIN – Gates Belt
FRONT BRAKE – Tektro HD-T280, 2 piston, 180mm disc
REAR BRAKE – Tektro HD-T280, 2 piston, 180mm disc
HANDLEBAR – Gazelle AeroLeder, luxury leather handlebar grips for a sophisticated feel and extra comfort
STEM – Ajustable
SEATPOST – Seatpost suspension
SADDLE – Selle Royal Lena Gel

The speed limit at which the motor will stop supporting may vary significantly by region and is based on local requirements. It may also affect range: a higher speed limit may result in less range.
